Alinco DJ-496T UHF FM Hand held Transceiver
Alinco has created a UHF FM Hand held Transceiver that sets new standards in features, convenience and ease of operation. The DJ-496T sports an alphanumeric display for easy memory management. It has an ergonomic design that' s " user friendly " and the 4 watt output battery is standard. You' ll be ready to travel the world with CTCSS encode + decode, DCS and European tone bursts, including all at no extra cost. Best of all, the DJ-496T remained proud Alinco tradition of quality construction and value.

• Alphanumeric display
• 40 memory channels + Call Channel
• Backlit Keypad
• 4 watt output with standard battery
• CTCSS encode + decode and DCS
• 13, 8 VDC direct input with battery features
• direct input frequency
• S-meter
• Autodialer
• Cable Cloning
• Computer programmable ( third party software required)
• MARS / CAP capability
• Additional features, including theft alarm!

Label the line alphanumeric display that is easy to read format. Displays frequency, alpha label or channel number only.
Memory Channel 40 + Call Channel Plenty room to store your favorite simplex or repeater frequencies along with alphanumeric label, offset, CTCSS encode / decode or DCS setting.
Standard 4 watt output battery allows the DJ-496T to produce up to 4 watts. A power input port
Received 13, 8 VDC battery and costs, but not too much damage.

CTCSS, DCS, and DTMF tone bursts prepared for virtually any selective calling situation or gaining access to repeaters with protected inputs. Tone bursts including Europe 1000, 1450, 1750 and 2100 Hz.
Direct Input Frequency entry is easy using the well-spaced keys.
S-Meter Displays the relative signal strength.
Cloning cable sharing identical arrangements of some of the DJ-496T transceivers. Saves time and ensures uniform operation.
Theft alarm The DJ-496T can be set to sound a tone when disconnected from external power source until proper action is taken to silence the alarm.
Experimental Insect Repel Feature Can the DJ-496T actually repel mosquitoes? Activate the special tone and decide for yourself! You can find DJ-496T can " de-bug " out of operating your website!

Specification

General DJ-496T
Frequency. RX original status 430-449, 995 MHz
Frequency. Stability of + / -5 ppm
Antenna imp. 50 ohm unbalanced
Supply Voltage DC 13.8V rated
DC 7.0min to 16V max
Negative ground GND
Event consumption TX 5W 1.4A approx.
13.8V outside source RX 200mA approx / 280mW
RX squelched 50mA approx.
RX Batt.Save on 20mA approx.
Operating temperature. range -10 to 60 degrees C.
Dimension w / o projection 56 ( W) x 124 ( H) x 40 ( D)
Weight with EBP-48N estimates. 375g ( 13.2oz)
Transmitter
Output power 5W 13.8V or 4W EBP-48N
Low = 0.8W
Modulation Variable reactance FM
Max. Deviation + / - 5kHz
Less-60dB spurious emissions
Imp microphone. 2k ohms approx.
